Big data and visualization hands-on lab step-by-step
Abstract and learning objectives
This hands-on lab is designed to provide exposure to many of Microsoft’s transformative line of business applications built using Microsoft big data and advanced analytics.
By the end of the lab, you will be able to show an end-to-end solution, leveraging many of these technologies, but not necessarily doing work in every component possible.
Overview
Margie’s Travel (MT) provides concierge services for business travelers. In an increasingly crowded market, they are always looking for ways to differentiate themselves, and provide added value to their corporate customers.
They are looking to pilot a web app that their internal customer service agents can use to provide additional information useful to the traveler during the flight booking process. They want to enable their agents to enter in the flight information and produce a prediction as to whether the departing flight will encounter a 15-minute or longer delay, considering the weather forecasted for the departure hour.
Solution architecture
Below is a diagram of the solution architecture you will build in this lab. Please study this carefully so you understand the whole of the solution as you are working on the various components.
Requirements
Microsoft Azure subscription must be pay-as-you-go or MSDN.
- Trial subscriptions will not work.
If you are not a Service Administrator or Co-administrator for the Azure subscription, or if you are running the lab in a hosted environment, you will need to install Visual Studio 2019 Community with the ASP.NET and web development and Azure development workloads.
Follow all the steps provided in Before the Hands-on Lab.
Exercise 1: Retrieve lab environment information and create Databricks cluster
Duration: 10 minutes
In this exercise, you will retrieve your Azure Storage account name and access key and your Azure Subscription Id and record the values to use later within the lab. You will also create a new Azure Databricks cluster.
Task 1: Retrieve Azure Storage account information and Subscription Id
You will need to have the Azure Storage account name and access key when you create your Azure Databricks cluster during the lab. You will also need to create storage containers in which you will store your flight and weather data files.
From the side menu in the Azure portal, choose Resource groups, then enter your resource group name into the filter box, and select it from the list.
Next, select your lab Azure Storage account from the list.
On the left menu, select Overview, locate and copy your Azure Subscription ID and save to a text editor such as Notepad for later.
Select Access keys (1) from the menu. Copy the storage account name (2) and the key1 key (3) and copy the values to a text editor such as Notepad for later.
Task 2: Create an Azure Databricks cluster
You have provisioned an Azure Databricks workspace, and now you need to create a new cluster within the workspace. Part of the cluster configuration includes setting up an account access key to your Azure Storage account, using the Spark Config within the new cluster form. This will allow your cluster to access the lab files.
From the side menu in the Azure portal, select Resource groups, then enter your resource group name into the filter box, and select it from the list.
Next, select your Azure Databricks service from the list.
In the Overview pane of the Azure Databricks service, select Launch Workspace.
Azure Databricks will automatically log you in using Azure Active Directory Single Sign On.
Select Clusters (1) from the menu, then select + Create Cluster (2).
On the New Cluster form, provide the following:
Cluster Name:
labCluster Mode: Standard
Pool: Select None
Databricks Runtime Version: Runtime: 6.4 (Scala 2.11, Spark 2.4.5) (Note: the runtime version CANNOT be > 6.6, due to compatibility issues with the supplied notebooks.)
Enable Autoscaling: Uncheck this option.
Terminate after: Check the box and enter
120Worker Type: Standard_F4s
Driver Type: Same as worker
Workers:
1Spark Config: Expand Advanced Options and edit the Spark Config by entering the connection information for your Azure Storage account that you copied above in Task 1. This will allow your cluster to access the lab files. Enter the following:
spark.hadoop.fs.azure.account.key.<STORAGE_ACCOUNT_NAME>.blob.core.windows.net <ACCESS_KEY>, whereis your Azure Storage account name, and is your storage access key.
Example:
spark.hadoop.fs.azure.account.key.bigdatalabstore.blob.core.windows.net HD+91Y77b+TezEu1lh9QXXU2Va6Cjg9bu0RRpb/KtBj8lWQa6jwyA0OGTDmSNVFr8iSlkytIFONEHLdl67Fgxg==
Select Create Cluster.
Exercise 2: Load Sample Data and Databricks Notebooks
Duration: 60 minutes
In this exercise, you will implement a classification experiment. You will load the training data from your local machine into a dataset. Then, you will explore the data to identify the primary components you should use for prediction, and use two different algorithms for predicting the classification. You will then evaluate the performance of both algorithms and choose the algorithm that performs best. The model selected will be exposed as a web service that is integrated with the optional sample web app at the end.
Task 1: Upload the Sample Datasets
Before you begin working with machine learning services, there are three datasets you need to load.
Download the three CSV sample datasets from here: http://bit.ly/2wGAqrl (If you get an error, or the page won’t open, try pasting the URL into a new browser window and verify the case sensitive URL is exactly as shown). If you are still having trouble, a zip file called AdventureWorksTravelDatasets.zip is included in the lab-files folders.
Extract the ZIP and verify you have the following files:
- FlightDelaysWithAirportCodes.csv
- FlightWeatherWithAirportCodes.csv
- AirportCodeLocationLookupClean.csv
Open your Azure Databricks workspace. Before continuing to the next step, verify that your new cluster is running. Do this by navigating to Clusters on the left-hand menu and ensuring that the state of your cluster is Running.
Select Data from the menu. Next, select default under Databases (if this does not appear, start your cluster). Finally, select Add Data above the Tables header.
Select Upload File under Create New Table, and then select either select or drag-and-drop the FlightDelaysWithAirportCodes.csv file into the file area. Select Create Table with UI.
Select your cluster to preview the table, then select Preview Table.
Change the Table Name to
flight_delays_with_airport_codesand select the checkmark for First row is header. Select Create Table.
Repeat steps 5 through 8 for the FlightWeatherWithAirportCode.csv and AirportCodeLocationsClean.csv files, setting the name for each dataset in a similar fashion:
- flightweatherwithairportcode_csv renamed to flight_weather_with_airport_code
- airportcodelocationlookupclean_csv renamed to airport_code_location_lookup_clean
Task 2: Install Azure ML library on the cluster
Select Clusters on the left-hand menu, then select your lab cluster to open it.
Select the Libraries tab. If you do not see the Azure ML library already installed on the cluster, continue to the next step. Otherwise, continue to Task 3.
Select Install New.
In the Install Library dialog, select PyPi for the Library Source, then enter the following in the Package field:
azureml-sdk[databricks]. Select Install.
Wait until the library’s status shows as Installed before continuing.
Task 3: Open Azure Databricks and complete lab notebooks
Within Azure Databricks, select Workspace on the menu, then Users, then select the down arrow next to your user name. Select Import.
Within the Import Notebooks dialog, select Import from: URL, then paste the following into the URL textbox:
https://github.com/microsoft/MCW-Big-data-and-visualization/blob/master/BigDataVis.dbc?raw=true.
After importing, expand the new BigDataVis folder.
Before you begin, make sure you attach your cluster to the notebooks, using the dropdown. You will need to do this for each notebook you open. There are 5 notebooks included in the BigDataVis.dbc
Run each cell of the notebooks located in the Exercise 2 folder (01, 02 and 03) individually by selecting within the cell, then entering Ctrl+Enter on your keyboard. Pay close attention to the instructions within the notebook so you understand each step of the data preparation process.
Do NOT run the
Clean uppart of Notebook 3 (i.e. this command:service.delete()). You will need the URL of your Machine Learning Model exposed later in Exercise 8: Deploy intelligent web app (Optional Lab).Note: you could get this URL by updating your Notebook and adding this line
print(service.scoring_uri), or by going to your Azure Machine Learning service workspace via the Azure portal and then to the “Deployments” blade.Do NOT run any notebooks within the Exercise 5 or 6 folders. They will be discussed later in the lab.
Exercise 3: Setup Azure Data Factory
Duration: 20 minutes
In this exercise, you will create a baseline environment for Azure Data Factory development for further operationalization of data movement and processing. You will create a Data Factory service, and then install the Data Management Gateway which is the agent that facilitates data movement from on-premises to Microsoft Azure.
Task 1: Download and stage data to be processed
Open a web browser.
Download the AdventureWorks sample data from http://bit.ly/2zi4Sqa.
Note: If you are using the optional VM provisioned in the Before the HOL document, ensure that you download and extract the data on the VM.
Extract it to a new folder called C:\Data.
Task 2: Install and configure Azure Data Factory Integration Runtime on your machine
To download the latest version of Azure Data Factory Integration Runtime, go to https://www.microsoft.com/en-us/download/details.aspx?id=39717.
Note: If you are using the optional VM provisioned in the Before the HOL document, ensure that you install the IR on the VM.
Select Download, then choose the download you want from the next screen.
Run the installer, once downloaded.
When you see the following screen, select Next.
Check the box to accept the terms and select Next.
Accept the default Destination Folder, and select Next.
Choose Install to complete the installation.
Select Finish once the installation has completed.
After selecting Finish, the following screen will appear. Keep it open for now. You will come back to this screen once the Data Factory in Azure has been provisioned, and obtain the gateway key so we can connect Data Factory to this “on-premises” server.
Task 3: Configure Azure Data Factory
Launch a new browser window, and navigate to the Azure portal (https://portal.azure.com). Once prompted, log in with your Microsoft Azure credentials. If prompted, choose whether your account is an organization account or a Microsoft account. This will be based on which account was used to provision your Azure subscription that is being used for this lab.
From the side menu in the Azure portal, choose Resource groups, then enter your resource group name into the filter box, and select it from the list.
Next, select your Azure Data Factory service from the list.
On the Data Factory Overview screen, select Author & Monitor.
A new page will open in another tab or new window. Within the Azure Data Factory site, select Manage on the menu.
Now, select Integration runtimes in the menu beneath Connections (1), then select + New (2).
In the Integration Runtime Setup blade that appears, select Azure, Self-Hosted, then select Continue.
Select Self-Hosted then select Continue.
Enter a Name, such as bigdatagateway-[initials], and select Create.
Under Option 2: Manual setup, copy the Key1 authentication key value by selecting the Copy button, then select Close.
Don’t close the current screen or browser session.
Paste the Key1 value into the box in the middle of the Microsoft Integration Runtime Configuration Manager screen.
Select Register.
It can take up to a minute or two to register. If it takes more than a couple of minutes, and the screen does not respond or returns an error message, close the screen by selecting the Cancel button.
The next screen will be New Integration Runtime (Self-hosted) Node. Select Finish.
You will then get a screen with a confirmation message. Select the Launch Configuration Manager button to view the connection details.
You can now return to the Azure Data Factory page, and view the Integration Runtime you just configured. You may need to select Refresh to view the Running status for the IR.
Select the Azure Data Factory Overview button on the menu. Leave this open for the next exercise.
Exercise 4: Develop a data factory pipeline for data movement
Duration: 20 minutes
In this exercise, you will create an Azure Data Factory pipeline to copy data (.CSV files) from an on-premises server (your machine) to Azure Blob Storage. The goal of the exercise is to demonstrate data movement from an on-premises location to Azure Storage (via the Integration Runtime).
Task 1: Create copy pipeline using the Copy Data Wizard
Within the Azure Data Factory overview page, select Copy Data.
In the Copy Data properties, enter the following:
Task name:
CopyOnPrem2AzurePipelineTask description: (Optional)
This pipeline copies time-sliced CSV files from on-premises C:\\Data to Azure Blob Storage as a continuous job.Task cadence or Task schedule: Select Run regularly on schedule
Trigger type: Select Schedule
Start date time (UTC): Enter 03/01/2018 12:00 AM
Recurrence: Every
1, and select Month(s)Under the Advanced recurrence options, make sure you have a value of
0in the textboxes for Hours (UTC) and Minutes (UTC), otherwise it will fail later during Publishing.End: No End
Select Next.
On the Source data store screen, select + Create new connection.
Scroll through the options and select File System, then select Continue.
In the New Linked Service form, enter the following:
Name:
OnPremServerConnect via integration runtime: Select the Integration runtime created previously in this exercise.
Host: C:\Data
User name: Use your machine’s login username.
Password: Use your machine’s login password.
Select Test connection to verify you correctly entered the values. Finally, select Create.
On the Source data store page, select Next.
On the Choose the input file or folder screen, select Browse, then select the FlightsAndWeather folder. Next, select Load all files under file loading behavior, check Recursively, then select Next.
On the File format settings page, select the following options:
File format: Text format
Column delimiter: Comma (,)
Row delimiter: Auto detect ( , or )
Skip line count:
0First row as header: Checked
Select Next.
On the Destination data store screen, select + Create new connection.
Select Azure Blob Storage within the New Linked Service blade, then select Continue.
On the New Linked Service (Azure Blob Storage) account screen, enter the following, test your connection, and then select Create.
Name:
BlobStorageOutputConnect via integration runtime: Select your Integration Runtime.
Authentication method: Select Account key
Account selection method: From Azure subscription
Storage account name: Select the blob storage account you provisioned in the before-the-lab section.
On the Destination data store page, select Next.
From the Choose the output file or folder tab, enter the following:
Folder path:
sparkcontainer/FlightsAndWeather/{Year}/{Month}/Filename:
FlightsAndWeather.csvYear: yyyy
Month: MM
Copy behavior: Merge files
Select Next.
On the File format settings screen, select the Text format file format, and check the Add header to file checkbox, then select Next. If present, leave Max rows per file and File name prefix at their defaults.
On the Settings screen, select Skip incompatible rows under Fault tolerance, and uncheck Enable logging. If present, keep Data concistency verification unchecked. Expand Advanced settings and set Degree of copy parallelism to
10, then select Next.
Review settings on the Summary tab, but DO NOT choose Next.
Scroll down on the summary page until you see the Copy Settings section. Select Edit next to Copy Settings.
Change the following Copy setting:
Retry:
3Select Save.
After saving the Copy settings, select Next on the Summary tab.
On the Deployment screen you will see a message that the deployment in is progress, and after a minute or two that the deployment completed. Select Edit Pipeline to close out of the wizard and navigate to the pipeline editing blade.
Exercise 5: Operationalize ML scoring with Azure Databricks and Data Factory
Duration: 20 minutes
In this exercise, you will extend the Data Factory to operationalize the scoring of data using the previously created machine learning model within an Azure Databricks notebook.
Task 1: Create Azure Databricks Linked Service
Return to, or reopen, the Author & Monitor page for your Azure Data Factory in a web browser, navigate to the Author view, and select the pipeline.
Once there, expand Databricks under Activities.
Drag the Notebook activity onto the design surface to the side of the Copy activity.
Select the Notebook activity on the design surface to display tabs containing its properties and settings at the bottom of the screen. On the General tab, enter
BatchScoreinto the Name field.
Select the Azure Databricks tab, and select + New next to the Databricks Linked service drop down. Here, you will configure a new linked service which will serve as the connection to your Databricks cluster.
On the New Linked Service dialog, enter the following:
Name:
AzureDatabricksConnect via integration runtime: Leave set to Default.
Account selection method: From Azure subscription
Azure subscription: Choose your Azure Subscription.
Databricks workspace: Pick your Databricks workspace to populate the Domain automatically.
Select cluster: Existing interactive cluster
Leave the form open and open your Azure Databricks workspace in another browser tab. You will generate and retrieve the Access token here.
In Azure Databricks, select the Account icon in the top corner of the window, then select User Settings.
Select Generate New Token under the Access Tokens tab. Enter ADF access for the comment and leave the lifetime at 90 days. Select Generate.
Copy the generated token and paste it into a text editor such as Notepad for a later step.
Switch back to your Azure Data Factory screen and paste the generated token into the Access token field within the form. After a moment, select your cluster underneath Choose from existing clusters. Select Create.
Switch back to Azure Databricks. Select Workspace > Users > BigDataVis in the menu. Select the Exercise 5 folder then open notebook 01 Deploy for Batch Scoring. Examine the content but don’t run any of the cells yet. You need to replace
STORAGE-ACCOUNT-NAMEwith the name of the blob storage account you copied in Exercise 1 into Cmd 4.
Switch back to your Azure Data Factory screen. Select the Settings tab, then browse to your Exercise 5/01 Deploy for Batch Score notebook into the Notebook path field.
The final step is to connect the Copy activities with the Notebook activity. Select the small green box on the side of the copy activity, and drag the arrow onto the Notebook activity on the design surface. What this means is that the copy activity has to complete processing and generate its files in your storage account before the Notebook activity runs, ensuring the files required by the BatchScore notebook are in place at the time of execution. Select Publish All, then Publish the CopyOnPrem2AzurePipeline, after making the connection.
Task 2: Trigger workflow
Switch back to Azure Data Factory. Select your pipeline if it is not already opened.
Select Trigger, then Trigger Now located above the pipeline design surface.
Enter
3/1/2017into the windowStart parameter, then select OK.
Select Monitor in the menu. You will be able to see your pipeline activity in progress as well as the status of past runs.
Note: You may need to restart your Azure Databricks cluster if it has automatically terminated due to inactivity.
Exercise 6: Summarize data using Azure Databricks
Duration: 10 minutes
In this exercise, you will prepare a summary of flight delay data using Spark SQL.
Task 1: Summarize delays by airport
Open your Azure Databricks workspace, expand the Exercise 6 folder and open the final notebook called 01 Explore Data.
Execute each cell and follow the instructions in the notebook that explains each step.
Exercise 7: Visualizing in Power BI Desktop
Duration: 20 minutes
In this exercise, you will create visualizations in Power BI Desktop.
Task 1: Obtain the JDBC connection string to your Azure Databricks cluster
Before you begin, you must first obtain the JDBC connection string to your Azure Databricks cluster.
In Azure Databricks, go to Clusters and select your cluster.
On the cluster edit page, scroll down to the bottom of the page, expand Advanced Options, then select the JDBC/ODBC tab.
On the JDBC/ODBC tab, copy and save the first JDBC URL.
Construct the JDBC server address that you will use when you set up your Spark cluster connection in Power BI Desktop.
Take the JDBC URL and do the following:
Replace
jdbc:sparkwithhttps.Remove everything in the path between the port number and sql, retaining the components indicated by the boxes in the image below. Also remove
;AuthMech=3;UID=token;PWD=<personal-access-token>from the end of the string.
In our example, the server address would be:
Task 2: Connect to Azure Databricks using Power BI Desktop
If you did not already do so during the before the hands-on lab setup, download Power BI Desktop from https://powerbi.microsoft.com/en-us/desktop/.
When Power BI Desktop starts, you will need to enter your personal information, or Sign in if you already have an account.
Select Get data on the screen that is displayed next.
Select Spark from the list of available data sources. You may enter Spark into the search field to find it faster.
Select Connect.
On the next screen, you will be prompted for your Spark cluster information.
Paste the JDBC connection string you constructed into the Server field.
Select the HTTP protocol.
Select DirectQuery for the Data Connectivity mode, and select OK. This option will offload query tasks to the Azure Databricks Spark cluster, providing near-real time querying.
Enter your credentials on the next screen as follows:
User name:
tokenPassword: Remember that ADF Access token we generated for the Azure Data Factory notebook activity? Paste the same value here for the password.
Select Connect.
In the Navigator dialog, check the box next to flight_delays_summary, and select Load.
Task 3: Create Power BI report
Once the data finishes loading, you will see the fields appear on the far side of the Power BI Desktop client window.
From the Visualizations area, next to Fields, select the Globe icon to add a Map visualization to the report design surface.
With the Map visualization still selected, drag the OriginLatLong field to the Location field under Visualizations. Then Next, drag the NumDelays field to the Size field under Visualizations.
You should now see a map that looks similar to the following (resize and zoom on your map if necessary):
Unselect the Map visualization by selecting the white space next to the map in the report area.
From the Visualizations area, select the Stacked Column Chart icon to add a bar chart visual to the report’s design surface.
With the Stacked Column Chart still selected, drag the DayofMonth field and drop it into the Axis field located under Visualizations.
Next, drag the NumDelays field over, and drop it into the Value field.
Grab the corner of the new Stacked Column Chart visual on the report design surface, and drag it out to make it as wide as the bottom of your report design surface. It should look something like the following.
Unselect the Stacked Column Chart visual by selecting on the white space next to the map on the design surface.
From the Visualizations area, select the Treemap icon to add this visualization to the report.
With the Treemap visualization selected, drag the OriginAirportCode field into the Group field under Visualizations.
Next, drag the NumDelays field over, and drop it into the Values field.
Grab the corner of the Treemap visual on the report design surface, and expand it to fill the area between the map and the side edge of the design surface. The report should now look similar to the following.
You can cross filter any of the visualizations on the report by selecting one of the other visuals within the report, as shown below (This may take a few seconds to change, as the data is loaded).
You can save the report, by choosing Save from the File menu, and entering a name and location for the file.
Exercise 8: Deploy intelligent web app (Optional Lab)
Duration: 20 minutes
In this exercise, you will deploy an intelligent web application to Azure from GitHub. This application leverages the operationalized machine learning model that was deployed in Exercise 1 to bring action-oriented insight to an already existing business process.
Please note: If you are running your lab in a hosted Azure environment and you do not have permissions to create a new Azure resource group, the automated deployment task (#2 below) may fail, even if you choose an existing resource group. The automated deployment will also fail if the user you are logged into the portal with is not a Service Administrator or a Co-Administrator. If this happens, we recommend that you install Visual Studio 2017/2019 Community or greater, then use the Publish feature to publish to a new Azure web app. You will then need to create and populate two new Application Settings as outlined in the tasks that follow:
mlUrlandweatherApiKey. Skip ahead to Task 3 for further instructions.
Task 1: Register for an OpenWeather account
To retrieve the 5-day hourly weather forecast, you will use an API from OpenWeather. There is a free version that provides you access to the API you need for this hands-on lab.
Navigate to https://openweathermap.org/home/sign_up.
Complete the registration form by providing your desired username, email address, and a password. Verify you are 16 years old and over, and agree to the privacy policy and terms of conditions. Select Create Account. If you already have an account, select Sign in at the top of the page instead.
Check your email account you used for registration. You should have a confirmation email from OpenWeather. Open the email and follow the email verification link within to complete the registration process. When the welcome page loads, log in with your new account.
After logging in, select the API keys tab. Take note of your Default Key and copy it to a text editor such as Notepad for later. You will need this key to make API calls later in the lab.
To verify that your API Key is working, replace {YOUR API KEY} in the following URL and paste the updated path to your browser’s navigation bar:
https://api.openweathermap.org/data/2.5/onecall?lat=37.8267&lon=-122.4233&appid={YOUR API KEY}. You should see a JSON result that looks similar to the following:
Note: If you send this request immediately after key creation, you may encounter a 401 response code. If so, wait for a couple of minutes.
Task 2: Deploy web app from GitHub
Navigate to https://github.com/Microsoft/MCW-Big-data-and-visualization/blob/master/Hands-on%20lab/lab-files/BigDataTravel/README.md in your browser of choice, but where you are already authenticated to the Azure portal.
Read through the README information on the GitHub page.
Select Deploy to Azure.
On the following page, ensure the fields are populated correctly.
Ensure the correct Directory and Subscription are selected.
Select the Resource Group that you have been using throughout this lab.
Either keep the default Site name, or provide one that is globally unique, and then choose a Site Location.
Enter the OpenWeather API Key.
Finally, enter the ML URL. We got this from Azure databricks Notebook #3 in the Exercise 2 folder. If you cleaned your resources at the end of this Notebook #3, you will need to re-run it and keep the web service running to get its associated URL.
Select Next, and on the following screen, select Deploy.
The page should begin deploying your application while showing you a status of what is currently happening.
Note: If you run into errors during the deployment that indicate a bad request or unauthorized, verify that the user you are logged into the portal with an account that is either a Service Administrator or a Co-Administrator. You won’t have permissions to deploy the website otherwise.
After a short time, the deployment will complete, and you will be presented with a link to your newly deployed web application. CTRL+Click to open it in a new tab.
Try a few different combinations of origin, destination, date, and time in the application. The information you are shown is the result of both the ML API you published, as well as information retrieved from the OpenWeather API.
Congratulations! You have built and deployed an intelligent system to Azure.
Task 3: Manual deployment (optional)
If the automated deployment from GitHub in the previous task failed, follow these instructions to manually deploy.
Install Visual Studio 2017/2019 Community or greater. Make sure you select the ASP.NET and web development and Azure development workloads.
Note: If you are prompted to sign in to Visual Studio for the first time, enter the Azure account credentials you are using for this lab.
In a web browser, navigate to the Big data and visualization MCW repo.
On the repo page, select Clone or download, then select Download ZIP.
Unzip the contents to your root hard drive (i.e.
C:\). This will create a folder on your root drive namedC:\MCW-Big-data-and-visualization-master.Open Windows Explorer and navigate to
C:\MCW-Big-data-and-visualization-master\Hands-on lab\lab-files\BigDataTravel\, then open BigDataTravel.sln.In the Visual Studio Solution Explorer, right-click on the BigDataTravel project, then select Publish….
In the Publish dialog, select the App Service publish target, select Create New, then choose Publish.
Enter the following into the App Service form that follows, then select Create:
Name: Enter a unique value.
Subscription: Choose the Azure subscription you are using for the lab.
Resource group: Select the Azure resource group you are using for the lab.
Hosting Plan: Select New, then create a new Hosting Plan in the same location and the Free size.
Application Insights: Select None.
After publishing is completed, open the new App Service located in your resource group in the Azure portal.
Select Configuration in the left-hand menu.
Create the two following Application settings, then select Save:
mlUrl: Enter the Machine Learning URL. We got this from Azure databricks Notebook #3 in the Exercise 2 folder. If you cleaned your resources at the end of this Notebook #3, you will need to re-run it and keep the web service running to get its associated URL.
weatherApiKey: Enter the OpenWeather API key.
You will now be able to successfully navigate the web app.
Note: If you receive an error concerning the Roslyn compiler, open the NuGet package manager interface (Tools –> NuGet Package Manager –> Package Manager Console) and run the command below to update the package. Then, publish the application again.
Update-Package Microsoft.CodeDom.Providers.DotNetCompilerPlatform -r
After the hands-on lab
Duration: 10 minutes
In this exercise, attendees will deprovision any Azure resources that were created in support of the lab.
Task 1: Delete resource group
Using the Azure portal, navigate to the Resource group you used throughout this hands-on lab by selecting Resource groups in the menu.
Search for the name of your research group and select it from the list.
Select Delete in the command bar and confirm the deletion by re-typing the Resource group name and selecting Delete.
You should follow all steps provided after attending the Hands-on lab.
Content from : https://cloudworkshop.blob.core.windows.net/big-data-vizualization/Hands-on%20lab/HOL%20step-by-step%20-%20Big%20data%20and%20visualization.html
0 Comments
